2001-2016 Duramax SoCal Alternative Firing Order Drag Racing/Sled Pulling #9100AF

Contact for availability
SKU: 9100AF
Regular price $1,599.99 CAD

Product details

  • Type Camshaft
  • Vendor SoCal Diesel
  • SKU 9100AF

Have any questions about this product?

Ask an expert at OCDiesel!

  • Extend the life of your crankshaft by changing the firing order of your engine.
  • The OEM firing order ends with cylinder 3 and begins with cylinders 1 and 2. The result is a 3-1-2 hit to the crankshaft. Duramax cranks have a tendency to break right behind the first rod throw at the intersection of the second main journal, right where the 3-1-2 hit would stress the crankshaft the most. Coincidence? We think not.
  • After carefully researching the different firing orders available to a V-8 engine, SoCal Diesel was the first to implement this "Alternative Firing Order" camshaft for the Duramax engine. In moving cylinders 3, 1 and 2 away from each other, we have significantly extended the abuse the crankshaft can withstand.
  • Swapping a few pins in the wiring harness will insure the ECM sends the injector signal to the correct cylinder. Wiring diagrams and instructions are included with every purchase.
  • Does not require any piston valve pockets.
  • Works well from idle past 3800 rpm
  • Valve Lash .012/.012
  • The camshaft is an integral part of your engine breathing characteristics
  • The camshaft lobe profiles need to be carefully matched to the rest of the engine components in order to achieve maximum performance for any given application.
  • We have designed profiles to meet many different applications that include dedicated Drag Racing and Sled Pulling

VALVE ADJUSTMENT PROCEDURE

  • Rotate the engine and adjust one cylinder at a time.
  • When the exhaust valves just begin to open, adjust the intake.
  • When the intake valves are just past maximum life, adjust the exhaust
